| Plattform | Consumer |
| Arkitektur | GCN 2.0 |
| Generation | Volcanic Islands |
| Föregående generation | Sea Islands |
| Nästa generation | Pirate Islands |
| Gränssnitt | PCIe 3.0 x16 |
| Namn | Hawaii x2 |
| Tillverkare | TSMC |
| Processnod | 28 nm |
| Transistorer | 6200 million |
| Chipstorlek | 438.0 mm² |
| Densitet | 14.2 /mm² |
| Kärnor | 2816 x2 |
| Compute Units | 44 x2 |
| TMU | 176 x2 |
| ROP | 64 x2 |
| Teknologi | GDDR5 |
| Storlek | 4 GB x2 |
| Buss | 512 bit x2 |
| Bandbredd | 320.0 GB/s x2 |
| Hastighet | 5.0 Gbps |
| Basfrekvens | 1030 MHz 1000 MHz |
| Minnefrekvens | 1250 MHz |
| 8-pin | 3 |
| DisplayPort | 1 1.2 |
| HDMI | 1 1.4a |
| DVI-D DL | 1 |
| Slot | 1 2 |
| Grafikkort▲ | Basfrekvens▲ | Slot▲ | Längd▲ | Höjd▲ | Bredd▲ |
|---|---|---|---|---|---|
| 1080 MHz +8.0% | 2.8 | 302 mm | 131 mm | 55 mm | |
| 1050 MHz +5.0% | 2 | 295 mm | 152 mm | 38 mm | |
| 1030 MHz +3.0% | 1 | ||||
| 1000 MHz | 2 | 295 mm | 152 mm | 38 mm | |
| 1000 MHz | 1.8 | 276 mm | 99 mm | 35 mm |
